I was able to carve out a little time to work on my project bike today--my assistant was off with his grandparents so I had to fly solo--swingarm, new shocks, and rear wheel assembly all went back on:



Lots left to do, but it is nice to see a little bit of progress after stalling out over the summer--I should have some time over the holidays to get after it again--I need to keep the momentum going--stay tuned . . .

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Dec 26, 2011 6:26 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Great day--rode the 919 for a 35 mile Christmas day ride (mid 40's but sunny and dry), then did a little bit of wrenching on the cafe build. Had to get organized first by laying out the hardware and assorted parts and getting the bike up on a rear stand:



Next, the battery box install:





Then, clean up the stock rectifier and attach to front of battery box:



I need to get some zip ties and connectors to clean up the wiring--lots to do--I have the day off tomorrow and will try to get the chief assistant back in the shop with me!

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Tue Dec 27, 2011 8:37 pm
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
I got my assistant back in the shop yesterday for some father and son wrenching.

Tach/speedo assembly:



Rearset assembly:



Kickstand:


Rearset bracket before and after installation:



Belt guard installation:



Tank mount assembly:


Seat pan/tank test fit:


Seat pan/seat/tank/side panel test fit:


Another test fit view:


Admiring our work:


Front end lowering mod is up next time we get back in the shop--stay tuned! :) :) :) :) :)

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Tue Jan 03, 2012 4:37 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
OK, as promised, pics of the front end lowering mod (plus clip-on install and front turn signal stalk mod). :) :) :) :) :)

Front wheel off:


Fork tubes removed:


Fork tubes disassembled (note custom damper removal tool in center of pic):


Damper rods:


Damper rods with spacers (this mod lowers the front end about 2-3"):


Clip-ons:


Modified fork tubes installed, along with clip-ons:


Levers installed (I will order a shorter brake line and will re-route some of the extra cable lengths):


Stock turn signal stalk:


One stock stalk, one modded stalk, and one new front signal:


I am having new rubber installed on the front rim--once I get the front wheel back on and let the bike down off the jack, she will start looking more like a cafe bike, I think. Stay tooned!

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 09, 2012 4:47 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Here we go--new rubber on front rim, front wheel installed:


Fork brace installed:


Check out the new stance with lowered front end! :love :love :love


Cables/wiring re-routed (shorter teflon brake line is being shipped):


Kickstand/brace parts:


Kickstand/brace assembly:


Kickstand installed--still needs a bit of adjustment:


Left rearset and shift linkage installed:


Right rearset and brake linkage installation:


Back to work tomorrow, so it will be next weekend before I get back in the shop. :( :( :(

BTW, my daughter told me this weekend that she did not think I would ever finish this project, so now I have some extra motivation. :) :) :)

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 09, 2012 1:05 pm
Offline
John Travolta (Are you Dancin'?)

Joined: Mon Aug 21, 2006 7:42 pm
Posts: 1881
Nice work....its not a 919 but keep it up :clap

_________________


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 09, 2012 5:05 pm
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Thanks--I've got some momentum going--I'm trying not to lose it.

And yes, it will be a much different bike from my 919, but a fun bike regardless, don't you think? :) :) :)

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 16, 2012 5:22 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Worked on the brakes this weekend--time consuming, but progress was made.

Replaced the stock front brake line with a custom 30" teflon line:

Front view (with the cleaned up look of front end due to shorter brake line):

Of course, nothing is ever simple--I had to disassemble, clean, and re-assemble the reservoir and caliper--the fluid was very dark and mucky. Here are the front reservoir assembly and caliper assembly after cleaning:


I fiddled with the rear brake linkage/right rearset assembly for quite a while before I got the adjustment right--here is the end result:


Day off tomorrow--hope to spend some more time in the shop--I may pull the right side engine cover and take a look at the cam chain tensioner--they are notorious for going bad on this bike between 15 and 20k miles--my bike has just over 19k.

Stay tuned . . .

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Last edited by bikertrash on Wed Jan 18, 2012 6:05 pm, edited 1 time in total.

Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Tue Jan 17, 2012 4:44 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Did not get into the shop until 8:00 pm (long story). Anyhow, I did pull the crankcase cover so I could look at the cam chain tensioner--although I don't think it is ready to fail, the plunger is at the wear limit (20 mm). So, I have ordered me up a tensioner mod from the suzukisavage.com website that will correct this issue. I will post pics of my bike soon, but in the meantime, the following link will show what this issue involves:

http://suzukisavage.com/cgi-bin/YaBB.pl ... 80206459/0

Back to work tomorrow, but I will post up more pics next weekend--stay tooned!

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Wed Jan 18, 2012 5:25 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Snuck over to the shop tonight to pluck the cam chain tensioner--as the pic shows, the plunger is extended about 20 mm, which is right at the wear limit. The assembly has been boxed up and will be shipped out tomorrow to be rebuilt.


Gotta keep making progress--ordered me up some mirrors from ebay this evening--is there anything better during the winter months than getting motorcycle parts in the mail? :angel :angel :angel

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 23, 2012 5:29 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Not much time spent in the shop this weekend, and my chief assistant was busy with ball games and such, so I was short handed.

I did, however, mangage to make a bit of progress, including getting the ignition switch ready for a relocation and re-wire:

Also, the back brake light cable reroute was finished up:

Finally, the decompression rod/lever assembly was sorted (installation to come later). The decompression lever replaces the decompression solenoid and serves to make start up easier, while reducing strain on the starter motor (necessary on a single cylinder 650 thumper). Once installed, the decompression lever can also be used as a killswitch (or a conversation topic at bike night).

Not the progress I had hoped, but the project continues to move forward. The rebuilt cam chain adjuster arrives next week, so I hope to get that installed and the crankcase cover buttoned back up at that time. Stay tuned . . .

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Sun Jan 29, 2012 5:24 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
OK cafe build fans, here is the latest update.

The rebuilt cam chain tensioner arrived this week--note the extension on the plunger. I also picked up a crankcase cover gasket:

Cam chain tensioner installed:

Fresh oil filter and filter cover installation by the chief assistant:

Drain plug installation prior to filling with fresh oil:

Mirror installation:

Mirrors installed--not sure I like this style or not:

Tachometer installation (a new throttle cable has been installed, along with throttle grip):

Speedometer installation:

Tach/speedo installed:

Another view of the tach/speedo:

Hope to get back in the shop tomorrow--maybe some wiring--maybe exhaust installation--stay tuned . . .

_________________
"Avoiding danger is no safer in the long run than outright exposure. Life is either a daring adventure or nothing."


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Sun Jan 29, 2012 11:09 am
Offline
Hornet Warrior
User avatar

Joined: Thu Oct 21, 2010 6:43 pm
Posts: 342
Location: That London (ish)
Hi Mate. What an absolutely inspiring thread - I've only just discovered it and read from start to finish - incredibly inspirational stuff and making me very jealous of the workshop facility that you have (my garage is far too small for something like this). Also very impressive to see the a) enthusiasm and b) capability of your able assistant. It's brilliant to see a young man interested in something more than mobile phones, X-boxes and the like. He is a credit to you and the rest of his family. I look forward immensely to the next instalment and ultimately the completed project. Well done fellah! :clap :clap

_________________
2003 600.Renthals,Black/Red short levers,Black/Red grips,Black pointy mirrors,black alloy footrests,Mivv X-Cone,small plate,LED indicators,No.plate lights,rear light/integral indies,cropped rear guard,HEL red brake hoses,stainless screws,Renthal sprockets,Tsubaki gold chain,stainless sprocket nuts


Top
 Profile

 Post subject: Re: ryca build project
 Post Posted: Mon Jan 30, 2012 4:14 am
Offline
Hornet Warrior
User avatar

Joined: Fri Jan 01, 2010 12:30 am
Posts: 225
Location: Ogden, Illinois, USA
Thanks for the kind words, FB. I am indeed fortunate to have the workshop space that I do--one of my good buddies was over for a little wrenching time not too long ago and commented: "you have it made." I have to agree.

This project has been a lot of fun over all, but is really testing my skill set--it is definitely a challenge, but I think I will have a much greater appreciation for this bike (once I finally get to ride it) as a result. I very much look forward to people asking me what it is and being able to tell them that "my son and I built it."

I did not grow up wrenching on things--my dad was a biker, but outsourced pretty much all of the work on his bikes. My son is gaining skills that I never had the opportunity to acquire when I was his age. And, I am getting real quality time with him and helping build lifelong memories for both of us.

So, with no further ado, here is the latest installment of the ryca build project.

I was able to install the exhaust system today--here is the exhaust pipe and connector:

Muffler, bracket, and hardware prior to install:

Two different views of the installed exhaust system:

Decompression mechanism installed--adjustment will come later:

Ignition installed in tank face plate:
